Round Shaft

Material: GB Q355B, in accordance with ASTM A572 Gr. 50
Dimension:

▶ Pipe: Accept customization


■  Outer Diameter: 2.875" /3.5"
  ■  Wall Thickness: 0.217”/0.254”/0.276”
  ■  Length: 5ft/7ft/10ft
▶ Helix: Accept customization


■  O.D.: 8"/10"/12"/14"
  ■  Type: Single/Double/Triple
  ■  Thickness: 0.375”/0.5”
  ■  Processing Method: Laser cut



Surface finished: Hot dip galvanizing, in accordance with ASTM A123/EN ISO 1461 standards for hot-dip zinc coatings.

Pipe size(inch)

Helix size(inch)

Length(ft)

2 7/8 * .217

10” single

5

2 7/8 * .217

12” single

5

2 7/8 * .217

10” single

7

2 7/8 * .217

12” single

7

2 7/8 * .217

8/10” double

7

2 7/8 * .217

10/12” double

7

2 7/8 * .217

12/14” double

7

2 7/8 * .217

8/10/12” Triple

7

2 7/8 * .217

10/12/14” Triple

7

2 7/8 * .276

10/12” Triple

7

2 7/8 * .276

12/14” Triple

7

3 1/2 * .217

8/10/12” Triple

7

3 1/2 * .254

8/10/12” Triple

7

Pipe size(inch)

Length(ft)

2 7/8 * .217

3

2 7/8 * .217

5

2 7/8 * .217

7

2 7/8 * .276

5

2 7/8 * .276

7
3 1/2 * .217

5
3 1/2 * .217

7
3 1/2 * .254

5

3 1/2 * .254

7
